Product Description
Need to rekey or expand a Sargent LFIC system without changing your locks? This Sargent 6-pin Large Format Interchangeable Core drops right into any Sargent LFIC-compatible lockset, lever, or deadbolt. Pull the existing core with a control key, slide this one in, and you're done — no disassembly, no removing the lock from the door.
✅ Keys Included — Ships combinated with 2 operating keys and 1 control key.
🛠 Pro-Tip from Our Locksmiths: Sargent's HA keyway is their most common restricted keyway for commercial LFIC work. If you're bidding a rekeying job, verify the existing keyway before ordering — Sargent has over 15 LFIC keyway families.
| Brand | Sargent |
| Part Number | 10-0617-3 |
| Core Type | LFIC (Large Format Interchangeable Core) |
| Pins | 6-Pin |
| Keying | Combinated (2 Operating Keys, 1 Control Key) |
| Finish | Bright Brass (605) |
| Cylinder Format | Figure-8 (Large Format) |
| Grade | ANSI/BHMA Grade 1 |
| Warranty | 7-10 Year Limited Warranty |
- Large Format Interchangeable Core — swap cores in seconds with a control key, no lock disassembly required
- Ships combinated with 2 operating keys and 1 control key included
- Compatible with all Sargent LFIC-format locksets, levers, and deadbolts
- In stock at Lock Depot — same-day shipping on orders placed before 3 PM EST
Works With: Compatible with all Sargent LFIC-format locksets including the 8200, 7800, and 6500 series. Need a housing? Shop Sargent Format LFIC Housings. Need the matching cores? Shop All Sargent LFIC Cores.
Image shown is representative of the product line. Actual finish, trim, and configuration may vary by SKU.
Warranty Information
Sargent (ASSA ABLOY) provides a limited warranty on all cylinders and cores covering defects in materials and workmanship from the date of shipment. Sargent cylindrical locksets carry a 7-year limited warranty; mortise locks carry a 10-year limited warranty. Cylinder components fall under the mechanical hardware warranty. For warranty claims, contact Sargent / ASSA ABLOY at 1-800-727-5477.Product Videos
Custom Field
Product Type Removable Core
Cylinder LFIC Core
Finish Bright Brass
Function Combinated
