    • 60-8204-LNP-4 Sargent 8200 Series Storeroom Mortise Lock in Satin Brass

    Sargent

    MSRP: $1,646.00
    $917.32
    (You save $728.68 )
    SKU:
    60-8204-LNP-4
    Condition:
    New
    Availability:
    available
    Product Type:
    Mortise Lock
    Function:
    Storeroom
    Series:
    8200
    Finish:
    Satin Brass
    Trim:
    LN Rose, P Lever
    Cylinder:
    Interchangeable Core
    Mount Type:
    Mortise
    Fire Rated:
    Fire Rated
    Adding to cart… category.add_cart_announcement

    Product Description

    If you've ever walked into a supply room and found it unlocked because someone forgot to relock the door — Storeroom function eliminates that problem permanently.

    The Sargent 60-8204-LNP-4 is a Storeroom function mortise lock from the 8200 Series — Sargent's flagship commercial mortise platform that's been trusted on schools, hospitals, office buildings, and government facilities for decades. Storeroom function means the outside lever is always locked — you need a key every single time you enter. Inside lever is always free for egress. No one can accidentally leave this door unlocked.

    SKU Breakdown: 60-8204-LNP-4
    60Electrified mortise lock (60 prefix)
    8204Series 8200, Storeroom function
    LNPTrim code: LNP
    4Finish code: 4
    LFIC Prep — Ships With Housing, Less Core — The 60- prefix means this lock ships with an LFIC housing (cylinder) instead of a standard pinned cylinder. Install the lock in the door first, then screw the LFIC housing into the lock body like any mortise cylinder. Order your LFIC core separately to match your building's keyway — the core snaps into the housing with a control key. No re-pinning, no tools, swap takes 10 seconds. That's why universities and hospitals love LFIC — one lost key doesn't mean rekeying a whole building.

    This one comes with LN Rose, P Lever in Satin Brass — the 04 finish making a huge comeback in commercial design. Popular on boutique hotels, upscale office buildings, and any project where the architect wants warm tones.

    Pro-Tip from Our Locksmiths: Don't confuse Storeroom with Entry/Office. Storeroom relocks every time the door closes — you need your key for every entry. Entry/Office stays unlocked after one key turn until you manually relock it. We get this call at least once a week: "My lock keeps locking me out!" — that's Storeroom working exactly as designed.
    CertificationANSI A156.13, BHMA Grade 1, UL 10C (3-Hour Fire Rating)
    Backset2-3/4"
    Face Size8" x 1-1/4"
    Warranty10-Year Limited. Contact ASSA ABLOY at 1-800-727-5477.
    • ANSI/BHMA Grade 1 — highest commercial security rating, tested to 1.5 million cycles
    • 3-hour fire rated — UL 10C listed for positive pressure fire test
    • LN Rose, P Lever — Sargent commercial trim
    • Satin Brass finish
    • Field reversible — works on left or right hand doors without modification

    Related Products:

    Authorized Sargent Distributor — Lock Depot is an authorized Sargent dealer. Every lock ships brand new in factory-sealed packaging with the full manufacturer warranty. We've been selling and installing Sargent hardware for over 20 years — if you need help specifying the right lock for your opening, call us at (877) 365-5625. We speak locksmith.

    Image shown is representative of this product line. Actual product matches your selected finish and configuration.

    Warranty Information

    Sargent provides a 10-year limited warranty on mortise locks covering defects in materials and workmanship under normal use and service. Warranty applies to the original purchaser when installed per Sargent specifications.

    Product Videos

    Custom Field

    Product Type Mortise Lock
    Function Storeroom
    Series 8200
    Finish Satin Brass
    Trim LN Rose, P Lever
    Cylinder Interchangeable Core
    Mount Type Mortise
    Fire Rated Fire Rated
