Product Description
The Sargent 60-8270-12V-LNL-10B is a 8200 Series Fail Safe mortise lock in Oil Rubbed Bronze (US10B/613). Unlocks on power loss for life safety egress.
Ships less cylinder — order a mortise cylinder separately to match your existing keyway.
| SKU Breakdown: 60-8270-12V-LNL-10B | |
| 60 | Series 8200, Fail Safe function |
| 8270 | Trim/lever design: LN Rose, L Lever |
| 12V | Finish: Oil Rubbed Bronze |
| LNL | Configuration modifier |
| 10B | Configuration modifier |
Pro-Tip from Our Locksmiths: When retrofitting from an older Sargent mortise lock, the 8200 drops right into the same prep — same backset, same strike. Save your customer the cost of new door prep.
| Brand | Sargent (ASSA ABLOY) |
| Part Number | 60-8270-12V-LNL-10B |
| Series | Sargent 8200 |
| Function | Fail Safe |
| Trim / Lever | LN Rose, L Lever |
| Finish | Oil Rubbed Bronze (US10B/613) |
| Mount Type | Mortise |
| Cylinder | Interchangeable Core |
| Fire Rating | Fire Rated — UL Listed |
| Voltage | 12/24VDC |
| Electronics | Electrified — see voltage and monitoring specs |
| Grade | ANSI/BHMA Grade 1 |
| Warranty | 10-Year Limited |
- Heavy-duty cast stainless steel chassis — built for millions of cycles in high-traffic environments
- Fail Safe function — Unlocks on power loss for life safety egress.
- Oil Rubbed Bronze (US10B/613) finish — durable commercial-grade coating
- ANSI/BHMA Grade 1 certified — highest commercial security rating
- Ships less cylinder — order a mortise cylinder separately to match your existing keyway.
Works With: Sargent 8200 Series mortise trim. Compatible with Sargent mortise cylinders in all standard keyways. For master key systems, consult your locksmith or call (877) 365-5625.
Image shown is representative of the product line. Actual finish, trim, and configuration may vary by SKU.
Warranty Information
Sargent provides a 3-year limited warranty on electromechanical components and a 10-year limited warranty on mechanical components of mortise locks, covering defects in materials and workmanship under normal use and service. Warranty applies to the original purchaser when installed per Sargent specifications. For warranty service, contact ASSA ABLOY Customer Care.Product Videos
Custom Field
Product Type Mortise Lock
Function Fail Safe
Series 8200
Finish Oil Rubbed Bronze
Trim LN Rose, L Lever
Cylinder Interchangeable Core
Mount Type Mortise
Fire Rated Fire Rated
Voltage 12/24VDC
Mode Fail Safe
