Product Description
Rekeying a building or setting up a new master key system? The Arrow Lock 7100CRP-UCXLB 26D is a 7-Pin uncombinated SFIC core in L - Best keyway, Satin Chrome (US26D/626). Ships with no pins, no springs, and no keys — your locksmith combinates it on site to match your building's keyway and master key system. Drop it into any standard SFIC housing and the operating key turns the lock while the control key swaps the core in seconds.
No Keys Included. This core ships uncombinated. Operating keys and control key must be ordered separately, or the core must be combinated by a qualified locksmith to match your keyway. SFIC control keys have completely different bitting than operating keys — they work a second shear line inside the figure-8 core to release the retaining lug.
Pro-Tip from Our Locksmiths: When ordering uncombinated cores for a master key system, order all cores in the same keyway at once so your locksmith can pin them up as a matched set. Not sure which keyway your building runs? Pull an existing core — the keyway letter is stamped on the face of the plug. Call (877) 365-5625 and we'll help you match it.
| Brand | Arrow Lock |
| Part Number | 7100CRP-UCXLB 26D |
| Type | SFIC Core — Small Format Interchangeable Core (Uncombinated) |
| Pin Configuration | 7-Pin — standard commercial |
| Keyway | L - Best — SFIC format, cross-compatible with all standard SFIC housings |
| Finish | Satin Chrome (US26D/626) |
| Finish Notes | The 626 Satin Chrome has a brushed matte silver look — hides fingerprints and wear marks better than Bright Chrome, which is why it's the go-to for high-traffic commercial doors. |
| Keys Included | No Keys Included |
| Core Format | Small Format IC (SFIC) — figure-8 profile, .450" diameter |
| Compatibility | Any standard SFIC housing — mortise, rim, knob/lever, padlock, cabinet |
| Grade | Meets ANSI/BHMA A156.5 standards for IC cylinders |
| Material | Brass plug and shell, nickel silver pins |
| Handing | Non-handed — works in any orientation |
| Warranty | Arrow Lock limited manufacturer warranty — covers defects in materials and workmanship |
- Drops into any standard SFIC housing — mortise cylinders, rim cylinders, knob/lever locks, padlocks, and cabinet locks
- Control key swaps the core in seconds without removing the lock from the door — rekey an entire building in a fraction of the time
- Figure-8 profile with .450" diameter — industry standard across all SFIC manufacturers
- Ships uncombinated — your locksmith pins it to your building's master key system for maximum security control
- Arrow Lock commercial grade — built for daily use in schools, hospitals, offices, and government buildings
Works With: Any standard SFIC housing from any manufacturer — Arrow, BEST, Falcon, Schlage, KSP, Kaba Ilco, Sargent, and Hager. Fits mortise cylinders, rim cylinders, knob/lever locks, padlocks, and cabinet locks with SFIC prep. If you're replacing an existing core, match the pin count (7-Pin) and keyway letter to your current system. Need help? (877) 365-5625.
Authorized Arrow Lock Distributor — Lock Depot is an authorized Arrow Lock dealer. Every product ships brand new in original manufacturer packaging with full factory warranty. Contact us or call (877) 365-5625 for expert assistance.
Image shown is representative of the product line. Actual finish, trim, and configuration may vary by SKU.
