Product Description
The Sargent 8204 is a Storeroom function mortise lock from the 8200 Series - Sargent's heavy-duty commercial mortise platform. Outside lever always locked, key required for every entry. Inside lever always free.
Ships without a cylinder installed. The photo above shows the lock with a mortise cylinder so you get the full picture of how it looks on the door. Browse compatible cylinders in Related Products below.
| Brand | Sargent (ASSA ABLOY) |
| Part Number | 8204 LSP 26D |
| Series | 8200 |
| Function | Storeroom (8204) |
| Trim | LS Escutcheon, P Lever |
| Finish | Satin Chrome (US26D/626) |
| Cylinder | Less Cylinder — compatible cylinders shown in Related Products below |
| Mount Type | Mortise |
| Fire Rating | Fire Rated - UL Listed |
| Grade | ANSI/BHMA Grade 1 |
| Warranty | 10 years (mechanical) |
- ANSI/BHMA Grade 1 - highest commercial security rating
- Fire rated mortise lock - UL Listed for fire-rated openings
- LS Escutcheon, P Lever - non-handed, works on left or right swing doors
- Ships less cylinder — check Related Products for Sargent OEM and generic cylinders that fit this lock
- Satin Chrome (US26D/626) - the most specified commercial finish, hides fingerprints and wear
Works With: Sargent 8200 Series mortise locks. Accepts standard mortise cylinders. Find the right cylinder for your keyway in Related Products below. If you need electrified access control on this opening, look at the 8270 (Fail Safe) or 8271 (Fail Secure) versions.
Authorized Sargent Dealer - Lock Depot ships all Sargent products brand new in factory-sealed packaging with the complete manufacturer warranty. Same day shipping available on most orders. Questions? Contact us for free expert support.
Image shown is representative of the product line. Actual finish, trim, and configuration may vary by SKU.
