Product Description
The Sargent 8237 is a Classroom function mortise lock from the 8200 Series - Sargent's heavy-duty commercial mortise platform. Outside lever locked until unlocked by key, relocks automatically when door closes. Inside always free.
Ships without a cylinder installed. The photo above shows the lock with a mortise cylinder so you get the full picture of how it looks on the door. Browse compatible cylinders in Related Products below.
| Brand | Sargent (ASSA ABLOY) |
| Part Number | 8237 LW1L 26D |
| Series | 8200 |
| Function | Classroom (8237) |
| Trim | LW1 Escutcheon, L Lever |
| Finish | Satin Chrome (US26D/626) |
| Cylinder | Less Cylinder — order a compatible cylinder from Related Products |
| Mount Type | Mortise |
| Fire Rating | Fire Rated - UL Listed |
| Grade | ANSI/BHMA Grade 1 |
| Warranty | 10 years (mechanical) |
- ANSI/BHMA Grade 1 - highest commercial security rating
- Fire rated mortise lock - UL Listed for fire-rated openings
- LW1 Escutcheon, L Lever - non-handed, works on left or right swing doors
- Ships less cylinder — see Related Products below for OEM Sargent cylinders and compatible aftermarket options
- Satin Chrome (US26D/626) - the most specified commercial finish, hides fingerprints and wear
Works With: Sargent 8200 Series mortise locks. This lock accepts any standard mortise cylinder — see Related Products below for Sargent OEM and aftermarket options to match your keyway. If you need electrified access control on this opening, look at the 8270 (Fail Safe) or 8271 (Fail Secure) versions.
Authorized Sargent Dealer - Lock Depot ships all Sargent products brand new in factory-sealed packaging with the complete manufacturer warranty. Same day shipping available on most orders. Questions? Contact us for free expert support.
Image shown is representative of the product line. Actual finish, trim, and configuration may vary by SKU.
