Product Description
Card access, keypads, fob readers — whatever access control system you're running, this electrified mortise lock is the hardware that makes it work. Fail Safe means the door unlocks when power goes out.
The Sargent 8272-24V-LNW-3 is a Fail Safe function mortise lock from the 8200 Series — Sargent's flagship commercial mortise platform that's been trusted on schools, hospitals, office buildings, and government facilities for decades. Fail Safe electric operation wired for 24VDC from your access control panel, card reader, or keypad system. The lock retracts the latch automatically when power is cut — code-required on fire-rated egress doors.
This one comes with LN Rose, W Lever in Bright Brass — the classic 03 finish. Traditional, formal, and still specified on government buildings, courthouses, and historic renovations.
| Certification | ANSI A156.13, BHMA Grade 1, UL 10C (3-Hour Fire Rating) |
| Backset | 2-3/4" |
| Face Size | 8" x 1-1/4" |
| Warranty | 3-Year Limited (electromechanical). Mechanical components: 10-Year Limited. Contact ASSA ABLOY at 1-800-727-5477. |
- ANSI/BHMA Grade 1 — highest commercial security rating, tested to 1.5 million cycles
- 3-hour fire rated — UL 10C listed for positive pressure fire test
- LN Rose, W Lever — Sargent commercial trim
- Bright Brass finish
- Field reversible — works on left or right hand doors without modification
