Product Description
XP98L-BE-12 4 32D LHR Von Duprin Extra Protection (XP) 98 Series Lever Blank Escutcheon Rim Exit Device Satin Stainless Steel
| Part Number Breakdown: XP98L-BE-12 4 32D LHR | |
|---|---|
| XP98 | Extra Protection 98 Series Rim Exit Device |
| L | Lever with Blank Escutcheon |
| BE | Blank Escutcheon (smooth plate, no cylinder opening) |
| 12 | 12 Lever Design |
| 32D | Satin Stainless Steel (BHMA 630) |
| 3 | 3 Foot Door |
| LHR | Left Hand Reverse |
The XP98L-BE-12 4 32D LHR is a Von Duprin XP98 Series Extra Protection rim exit device with Lever Blank Escutcheon trim in Satin Stainless Steel, sized for 3 Foot doors. Lever Trim with Blank Escutcheon — smooth plate on the outside trim with no cylinder opening. Outside lever locked/unlocked by key, always free from inside. Ships less cylinder — order a mortise cylinder separately.
ANSI/BHMA A156.3 Grade 1 certified. Hex key dogging standard. Field reversible handing. The XP (Extra Protection) model features a reinforced shield over the mechanism case — designed for high-abuse environments where standard exit devices take damage.
Pro-Tip from Our Locksmiths: Blank Escutcheon on the XP98 lever trim gives you a clean, flat plate on the outside — no cylinder hole visible. This is the spec when you want a keyed lever function but don't want the cylinder opening on the escutcheon plate. Order a mortise cylinder separately. The XP mechanism case protects against the vandalism that's common in high-traffic facilities.
| Specifications | |
|---|---|
| Part Number | XP98L-BE-12 4 32D LHR |
| Brand | Von Duprin (Allegion) |
| Series | Von Duprin XP98 |
| Function | Night Latch |
| Lever Design | L-12 Lever |
| Grade | ANSI/BHMA A156.3 Grade 1 |
| Mount Type | Rim (horizontal latch bolt — strikes into frame on lock side) |
| Finish | Satin Stainless Steel (32D/630) |
| Door Size | 3 Foot |
| Handing | Left Hand Reverse |
| Cylinder | Less Cylinder |
| Fire Rating | Non Fire Rated |
- Von Duprin XP98 Series Extra Protection touch bar mechanism — Grade 1 architectural-grade panic hardware with reinforced mechanism shield
- Rim (horizontal latch bolt — strikes into frame on lock side)
- Satin Stainless Steel finish
- Hex key dogging standard — hold latch retracted during business hours
- Ships less cylinder — order separately to match your keyway
Cross-Reference: The XP98 is the vandal-resistant upgrade to the standard Von Duprin 98 Series. Same mounting prep, same strike, same trim compatibility — but with the reinforced mechanism case for high-abuse environments. Compatible with all 98 Series trim options (L, K, NL, TP, DT).
Free Expert Support — As an authorized Von Duprin distributor, Lock Depot provides full manufacturer warranty coverage and same day shipping on most orders. Call (877) 365-5625 for personalized help.
Image shown is representative of the product line. Actual finish, trim, and configuration may vary by SKU.
