Product Description
The Sargent 25-CPSH-3 (our part number 25CPSH-3) is the heavy duty parallel arm with hold open and built-in compression stop for Sargent surface closers, in 3 — US3 / 605 bright brass finish. This is the arm only — the closer body is not included. It is the same 25-CPSH arm Sargent lists for its 351, 281 and 1431 series closers.
Order it when the arm on your existing Sargent closer is bent, worn or broken and the closer body itself is still good. The arm holds the door open at the point you set, and the compression stop built into the arm stops the swing at the frame instead of letting the door, closer and hinges take the hit.
| Brand | Sargent (ASSA ABLOY) |
| Part Number | 25-CPSH-3 (Lock Depot SKU 25CPSH-3) |
| Product | Heavy Duty Parallel Arm with Hold Open and Compression Stop (CPSH) |
| Fits | Sargent 351, 281 and 1431 series door closers |
| Finish | 3 — US3 / 605 bright brass |
| Mounting | Parallel arm, push side of the door |
| What is included | Complete CPSH arm: main arm, parallel arm bracket and screw pack |
| Closer body | Not included — sold separately |
Parts in this arm (Sargent 281 / 351 / 1431 Series Parts Manual 90902, page 11, "25-CPSH Heavy Duty Parallel Arm with Hold Open and Compression Stop"):
- 63-3836 bracket assembly
- 63-0641 main arm
- 63-3487 screw pack (pivot, screw, bumper holder, bumper, insert, spacer)
If only one piece is broken, those parts are sold separately in the matching finish.
Pro-Tip from Our Locksmiths: Check what you have before you order. The model number is cast or stamped on the closer body — look for 351, 281 or 1431. Then look at the arm: a CPSH arm holds the door open as well as stopping it; a CPS arm only stops it. They are different arms, so order the one you are replacing.
Works With: Sargent 351, 281 and 1431 series closers mounted parallel arm. Not for a regular-arm (pull side) or top jamb mounting.
Every product includes the full manufacturer warranty. Not sure which arm you need? Call (877) 365-5625.
