Product Description
The Sargent 2870-7G04-LB-10B is a 7 Line cylindrical lock with Storeroom function in Oil Rubbed Bronze (US10B/613). Outside lever is always locked — key required for every entry. Inside lever is always free for exit. Grade 2 certified for standard-duty commercial use.
Ships prepped for a Small Format Interchangeable Core (SFIC) with a plastic disposable construction core (70- option) — the permanent SFIC core is not included. Order your SFIC (Best-style) core separately to match your key system; it drops into the figure-8 housing with a control key for an instant rekey without removing the lock.
| SKU Breakdown: 2870-7G04-LB-10B | |
| 2870 | 28 = 808 ANSI strike; 70 = accepts 6- or 7-pin SFIC (disposable plastic core provided) |
| 7G04 | Series and Storeroom function |
| LB | Trim: B Lever |
| 10B | Finish: Oil Rubbed Bronze |
Pro-Tip from Our Locksmiths: Sargent cylindrical locks are a solid mid-range choice for commercial jobs where mortise prep isn't in the budget. Grade 2 certified with a clean, professional look.
| Brand | Sargent (ASSA ABLOY) |
| Part Number | 2870-7G04-LB-10B |
| Function | Storeroom |
| Trim / Lever | B Lever |
| Finish | Oil Rubbed Bronze (US10B/613) |
| Mount Type | Cylindrical |
| Cylinder | SFIC prep (70-): plastic disposable construction core provided |
| Grade | ANSI/BHMA A156.2 Series 4000, Grade 2 |
| Warranty | 5-Year Limited |
- ANSI/BHMA A156.2 Series 4000, Grade 2 cylindrical lock — standard commercial duty
- Storeroom function for commercial access control
- Oil Rubbed Bronze (US10B/613) finish
- Standard ANSI/161 prep — drops into existing cutouts
Works With: Standard ANSI prep doors. If you're replacing Schlage or Arrow cylindrical locks, verify your door prep — Sargent uses standard 161 cutout.
Authorized Sargent Dealer — Lock Depot ships all Sargent products brand new in factory-sealed packaging with the complete manufacturer warranty. Same day shipping available on most orders. Questions? Contact us for free expert support.
Image shown is representative of the product line. Actual finish, trim, and configuration may vary by SKU.
