Product Description
30-021-C235-114-609 Schlage Conventional Rim Cylinder 1-1/4 in cylinder length, Classic C235 multi-section keyway (Classic family) — Antique Bronze (US5)
When a Schlage mortise or rim device needs a replacement plug or a rekeyed cylinder that matches the building's keyway, the wrong cam length or keyway family means a return trip. The Schlage 30-021-C235-114-609 is a conventional rim cylinder cut to the Classic C235 multi-section keyway (Classic family) in Antique Bronze (US5), built to drop into the matching Schlage housing. Verify cam, length, and keyway against your host device before ordering.
SKU Breakdown
| Segment | Code | What It Means |
|---|---|---|
| Cylinder Type | 30 | Conventional rim cylinder |
| Model | 021 | Schlage cylinder model 021 |
| Keyway | C235 | Classic C235 multi-section keyway (Classic family) |
| Length | 114 | 1-1/4 in cylinder length |
| Finish | 609 | Antique Bronze (US5) |
Technical Specifications
| Specification | Value |
|---|---|
| SKU | 30-021-C235-114-609 |
| Brand | Schlage (Allegion) |
| Product Type | Commercial Mortise/Rim Cylinder |
| Cylinder Type | Conventional Rim Cylinder |
| Keyway | Classic C235 multi-section keyway (Classic family) |
| Length | 1-1/4 in cylinder length |
| Finish | 609 — Antique Bronze (US5) |
| Pin Configuration | 6-pin conventional (mortise/rim) or 7-pin SFIC core per prefix |
| Keys Included | Two nickel-silver cut keys per cylinder (keyed) |
| Compatibility | Drops into the matching Schlage mortise or rim housing; verify cam, length, and keyway against the host device before ordering |
| Warranty | Schlage limited warranty |
| Lock Depot Price | $74.93 |
| MSRP (List) | $111.00 |
Compliance & Codes
Everest 29 (patented), Classic (open), Best A/C/L/etc (SFIC), or Primus XP per the keyway token in the SKU. UL 437 Listed when using a UL 437 Primus cylinder. Match the security level to the host lock.
What's in the Box
One Schlage conventional rim cylinder (1-1/4 in cylinder length) in Antique Bronze (US5), two nickel-silver cut keys per cylinder (keyed).
Pro-Installer FAQ
Q: Will the 30-021-C235-114-609 fit my existing Schlage lock?
A: Drops into the matching Schlage mortise or rim housing; verify cam, length, and keyway against the host device before ordering
Q: What keyway is this and can it be master keyed?
A: Classic C235 multi-section keyway (Classic family). Schlage cylinders support master keying and construction keying within the matching keyway family.
Q: How many keys come with it?
A: Two nickel-silver cut keys per cylinder (keyed)
Lock Depot sells brand new Schlage products with the full manufacturer warranty.
Product images are representative and may not depict the exact SKU, finish, or configuration listed. Always verify specifications before ordering.
