Product Description
The Sargent LC-8243-WTA-32D-LH is an Apartment Corridor function mortise lock from the 8200 Series — Sargent's flagship commercial mortise platform that's been trusted on schools, hospitals, office buildings, and government facilities for decades. Key and thumbturn both retract & project the deadbolt. Trim outside is locked by toggle or projecting deadbolt. Trim outside is unlocked by toggle only. Key retracts both latchbolt and deadbolt, trim outside remains locked. Trim inside always retracts latchbolt (and deadbolt simultaneously), trim outside remains locked. Auxiliary deadlatch.
| SKU Breakdown: LC-8243-WTA-32D-LH | |
| LC | Less cylinder |
| 8243 | Series 8200, Apartment Corridor function |
| WTA | Trim code: WTA |
| 32D | Finish: Satin Stainless |
| LH | Left Hand |
This one comes with WT Escutcheon, A Lever in Satin Stainless — the 32D finish that laughs at corrosion. Coastal, pool areas, food service, anywhere moisture is a factor. Costs more than chrome but outlasts it 3-to-1 in harsh environments.
| Handing | Left Hand |
| Certification | ANSI A156.13, BHMA Grade 1, UL 10C (3-Hour Fire Rating) |
| Backset | 2-3/4" |
| Face Size | 8" x 1-1/4" |
| Warranty | 10-Year Limited. Contact ASSA ABLOY at 1-800-727-5477. |
- ANSI/BHMA Grade 1 — highest commercial security rating, tested to 1.5 million cycles
- 3-hour fire rated — UL 10C listed for positive pressure fire test
- WT Escutcheon, A Lever — Sargent commercial trim
- Satin Stainless finish
